OPERATING ROOMS SPACE SAVING SOLUTIONS FOR PERSONALIZED FOR CHILDREN NEONATES TO ADOLESCENTS HELP TO PROTECT SKIN AND SOFT TISSUES
ULTIMATE IN EASY AND consistent application IN THE FIELD HOSPITAL SAFETY AND PERFORMANCE
Delfi's surgical line of tourniquet instruments and cuffs are designed for safety, performance and ease of use. Today, our patented, proven and innovative technologies are used worldwide in over 20,000 surgical cases each day.

The PTS system's compact design and configuration options make it the ideal solution for use in operating rooms and by medics on the move. Delfi's complimentary lines of PTS Tourniquet Cuffs are designed to provide the perfect fit for every patient, helping surgeons and operating-room nurses deliver personalized safe and effective care for their patients.
Resources

Delfi Surgical Products Catalog

Limb Circumference Chart - PTS Tourniquet Cuffs, Reusable

Limb Circumference Chart - PTS Tourniquet Cuffs, Single-Use

Cuff Selection Guide

Recommended Tourniquet Cuff Selection

Determine the patient’s limb shape using diagrams below. Measure the patients limb circumference, then refer to the Limb Circumference Chart for cuff selection.

To ensure the selected cuff is the correct size for the patient, verify there is sufficient overlap for the Secondary Fastener (located on underside) to fully engage with the loop material on surface of the cuff. Secondary Fasteners provide added stability to the cuff during use.

Cylindrical & Tapered
Neonate to Adolescent
 and Small Adult Limbs

Select a Pedi-Fit or Petite-Fit Cuff and Matching Limb Protection Sleeve

For neonates, children, and adults with small limbs, select a cylindrical cuff having the most appropriate width for surgical exposure.

Tapered
 Adult Limbs

Select an Easi-Fit or Vari-Fit Contour Cuff and Matching Limb Protection Sleeve

A unique contour shape and pivoting fasteners allow the cuff to conform to a variety of tapered (conical) limb shapes.

Cylindrical
XL  Adult Limbs

Select an Easi-Fit Cylindrical Cuff and Matching Limb Protection Sleeve

A cylindrical cuff provides the best fit for cylindrical shaped and bariatric limbs.

WARNING: For Delfi’s PTS tourniquet instruments and cuffs, always follow manufacturer’s detailed instructions.

Download PDF

Cuff Application Guide

Recommended Tourniquet Cuff Application

This Guide was prepared in consultation with James McEwen, PhD, the inventor of automatic tourniquets, to summarize relevant published guidelines and recommendations.*

Select the most appropriate tourniquet cuff considering limb size and shape, and the specific procedure:

  • Cuff shape should allow a snug fit along both proximal and distal edges.
  • Cuff width should be the greatest width that still assures recommended distances from cuff edges to limb joints and surgical site.
  • Cuff length should be the minimum that assures overlap around the limb sufficient to fully engage fasteners.

Use limb protection, ideally a sleeve specifically matched to the selected cuff.

A limb protection sleeve matched to the size and shape of the selected cuff provides the best protection against skin wrinkling, bruising and other soft tissue injuries to the limb beneath the cuff.*

Apply the selected tourniquet cuff snugly on the limb, over limb protection.

A snugly applied cuff allows two fingers easily under the cuff at both proximal and distal edges. If only one finger fits, the cuff is too tight; if three fingers fit, the cuff is too loose.

A loose cuff will require higher pressure to stop blood flow and may slide to an unsafe position on the limb during use. A tight cuff could impede venous return of blood from the limb even when deflated.

After cuff application, the limb distal to the cuff should be exsanguinated by elastic bandage or elevation, as determined by the surgeon.

An automatic tourniquet instrument with modern safety features and audio-visual alarms should be used with the cuff.

The optimum tourniquet pressure for each patient and cuff application can be set or checked by measuring Limb Occlusion Pressure (LOP).*

Intraoperative monitoring of tourniquet safety parameters reduces the risk of complications. During the procedure, it is important to monitor tourniquet pressure and time, and to minimize both.

Upon final deflation of the tourniquet, the tourniquet cuff and underlying limb protection should be immediately removed from the limb.

* Refer to www.tourniquets.org for an expanded guide and relevant references.

WARNING: For specific tourniquet instruments and cuffs, always follow manufacturers’ instructions.

Download PDF

Related Links

Additional Information and Links

www.tourniquets.org
An educational website focused on surgical tourniquets, including tourniquet technology, tourniquet safety and surgical usage, with the goal of providing comprehensive information leading to safer and more effective use of surgical tourniquet systems.

www.aorn.org
AORN is the Association of periOperative Registered Nurses, a professional organization of whose mission is to promote quality patient care by providing its members with education, standards, services, and representation.

www.zimmer.com
Zimmer Inc. is a leading supplier of tourniquet systems, including instruments, cuffs and accessories, and Zimmer is the exclusive distributor of some Delfi products.
